2025 Amflow PL Carbon 800Wh
$9,400.00 Incl. tax
Add to cart
2025 Amflow PL Carbon 800Wh
Amflow
(0)
2025 Amflow PL Carbon 800Wh
2025 Amflow PL Carbon 800Wh
Amflow
0 reviews

2025 Amflow PL Carbon 800Wh

$9,400.00 Incl. tax
In stock
Available in store

The Amflow PL Carbon features a lightweight carbon frame, 800Wh Avinox drive, and 2-inch OLED display for smooth, efficient, and long-range e-bike performance. Read more.

Add to compare

Product description

5 Modes, Effortless Assistance

Auto mode adapts assistance in real-time. Activate Boost mode to instantly get 120 N·m of torque and 1000W high-power assistance.

Light Motor, Powerful Drive

The 2.52kg motor delivers 105N·m continuous torque and 1000W peak power. Strong and durable polymer material effectively suppresses noise.

Ultra-Light Streamlined Frame

The 19.2kg build uses an ultra-light carbon fiber frame that weighs just 2.27 kg, for breathtaking speed and agility.

800Wh Batt., 3x Fast Charging

Using the Avinox Drive System that provides battery with a maximum capacity of 800 Wh, the bike can reach a range of 157 km.

Versatile Geometry

Amflow PL's frame design features a 64.5° head tube angle, a 445mm chainstay length, and a 77° seat tube angle, offering balanced performance.

Built-in Touchscreen Display

The 2-inch full-color OLED touchscreen offers real-time ride data and range. Paired with the Avinox app, it offers remote locating features.

Amflow PL Carbon (800Wh)

Frame

  • Amflow PL Carbon Frame
  • Satin Silver
  • 150mm rear travel
  • Compatible with 27.5" and 29" rear wheels

E-Bike System

  • Avinox M1 Drive Unit: 105 N·m
  • Avinox Screen: 2-inch OLED Control Display
  • Avinox Integrated Battery: 800Wh
  • Avinox Wireless Controllers: Right and left sides
  • Avinox Fast Charger: 12A/508W

Fork

  • 2026 FOX 36 Performance
  • 160mm travel, GRIP Damper, 15×110mm, 44mm rake

Rear Shock

  • 2026 FOX Float Performance
  • Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever

Transmission

  • Rear Derailleur: SRAM Eagle 70 Transmission Derailleur
  • Chainring: SRAM Eagle Transmission E-MTB Chainring 104BCD 34T
  • Shift Levers: SRAM Eagle 70 Transmission Shifter | Single Click
  • Cassette: SRAM XS-1270 Eagle Transmission 10-52T
  • Chain: SRAM Eagle 70 Transmission Flattop Chain
  • Crankset: Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm)

Brakes

  • Magura MT5 hydraulic disc brake, HC lever, 4-piston caliper w/ Shiftmix 3, 203mm MDR-C Rotor (front and rear)

Wheels

  • Amflow HMA-30
  • Rims: Alloy, 29'', 30mm internal width, 32H, tubeless ready
  • Spokes: SAPIM E-Light J-bend
  • Front Hub: Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 32h, 6-bolt
  • Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 32h, 6-bolt, 21T

Tires

  • Front: Maxxis Assegai MaxxTerra 29×2.5" WT 3C EXO E-25 TLR
  • Rear: Max
