5 Modes, Effortless Assistance

Auto mode adapts assistance in real-time. Activate Boost mode to instantly get 120 N·m of torque and 1000W high-power assistance.

Light Motor, Powerful Drive

The 2.52kg motor delivers 105N·m continuous torque and 1000W peak power. Strong and durable polymer material effectively suppresses noise.

Ultra-Light Streamlined Frame

The 19.2kg build uses an ultra-light carbon fiber frame that weighs just 2.27 kg, for breathtaking speed and agility.

800Wh Batt., 3x Fast Charging

Using the Avinox Drive System that provides battery with a maximum capacity of 800 Wh, the bike can reach a range of 157 km.

Versatile Geometry

Amflow PL's frame design features a 64.5° head tube angle, a 445mm chainstay length, and a 77° seat tube angle, offering balanced performance.

Built-in Touchscreen Display

The 2-inch full-color OLED touchscreen offers real-time ride data and range. Paired with the Avinox app, it offers remote locating features.

Frame

• Amflow PL Carbon Frame
• Satin Silver
• 150mm rear travel
• Compatible with 27.5" and 29" rear wheels

E-Bike System

• Avinox M1 Drive Unit: 105 N·m
• Avinox Screen: 2-inch OLED Control Display
• Avinox Integrated Battery: 800Wh
• Avinox Wireless Controllers: Right and left sides
• Avinox Fast Charger: 12A/508W

Fork

• 2026 FOX 36 Performance
• 160mm travel, GRIP Damper, 15×110mm, 44mm rake

Rear Shock

• 2026 FOX Float Performance
• Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever

Transmission

• Rear Derailleur: SRAM Eagle 70 Transmission Derailleur
• Chainring: SRAM Eagle Transmission E-MTB Chainring 104BCD 34T
• Shift Levers: SRAM Eagle 70 Transmission Shifter | Single Click
• Cassette: SRAM XS-1270 Eagle Transmission 10-52T
• Chain: SRAM Eagle 70 Transmission Flattop Chain
• Crankset: Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm)

Brakes

• Magura MT5 hydraulic disc brake, HC lever, 4-piston caliper w/ Shiftmix 3, 203mm MDR-C Rotor (front and rear)

Wheels

• Amflow HMA-30
• Rims: Alloy, 29'', 30mm internal width, 32H, tubeless ready
• Spokes: SAPIM E-Light J-bend
• Front Hub: Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 32h, 6-bolt
• Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 32h, 6-bolt, 21T

Tires

• Front: Maxxis Assegai MaxxTerra 29×2.5" WT 3C EXO E-25 TLR
• Rear: Max
