2025 Amflow PL Carbon Pro 800Wh
$14,000.00 Incl. tax
Add to cart
2025 Amflow PL Carbon Pro 800Wh
Amflow
(0)
2025 Amflow PL Carbon Pro 800Wh
2025 Amflow PL Carbon Pro 800Wh
Amflow
0 reviews

2025 Amflow PL Carbon Pro 800Wh

$14,000.00 Incl. tax
In stock
Available in store

The Amflow PL Carbon Pro combines a high-end carbon frame, upgraded components, 800Wh Avinox drive, and 2-inch OLED display for powerful, agile, and long-range riding. Read more.

Add to compare

Product description

5 Modes, Effortless Assistance

Auto mode adapts assistance in real-time. Activate Boost mode to instantly get 120 N·m of torque and 1000W high-power assistance.

Light Motor, Powerful Drive

The 2.52kg motor delivers 105N·m continuous torque and 1000W peak power. Strong and durable polymer material effectively suppresses noise.

Ultra-Light Streamlined Frame

The 19.2kg build uses an ultra-light carbon fiber frame that weighs just 2.27 kg, for breathtaking speed and agility.

800Wh Batt., 3x Fast Charging

Using the Avinox Drive System that provides battery with a maximum capacity of 800 Wh, the bike can reach a range of 157 km.

Versatile Geometry

Amflow PL's frame design features a 64.5° head tube angle, a 445mm chainstay length, and a 77° seat tube angle, offering balanced performance.

Built-in Touchscreen Display

The 2-inch full-color OLED touchscreen offers real-time ride data and range. Paired with the Avinox app, it offers remote locating features.

Amflow PL Carbon Pro (800Wh)

Frame

  • Amflow PL Carbon Frame
  • Cosmic Black
  • 150mm rear travel
  • Compatible with 27.5" and 29" rear wheels

E-Bike System

  • Avinox M1 Drive Unit: 105 N·m
  • Avinox Screen: 2-inch OLED Control Display
  • Avinox Integrated Battery: 800Wh
  • Avinox Wireless Controllers: Right and left sides
  • Avinox Fast Charger: 12A/508W

Fork

  • 2026 FOX 36 Factory
  • 160mm travel, GRIP X2 Damper, 15×110mm, 44mm rake

Rear Shock

  • 2026 FOX FLOAT X Factory
  • Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever w/ LSC adjustment

Transmission

  • Rear Derailleur: SRAM X0 Eagle Transmission Derailleur w/ power cable
  • Chainring: SRAM Eagle Transmission E-MTB Chainring 104BCD 34T
  • Shift Levers: SRAM AXS Pod Controller
  • Cassette: SRAM XS-1295 Eagle Transmission 10-52T
  • Chain: SRAM X0 Eagle Transmission Flattop Chain
  • Crankset: Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm)

Brakes

  • Magura MT7 Pro hydraulic disc brake, HC lever, 4-piston caliper
  • 203mm Storm HC Rotor (front and rear)

Wheels

  • Amflow HMC-30
  • Rims: Carbon, 29'', 30mm internal width, 28H, tubeless ready
  • Spokes: SAPIM E-Light Straightpull
  • Front Hub: Alloy, 2 sealed cartridge bearings, 15×110mm thru-axle, 28h, straight-pull, 6-bolt
  • Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12mm thru-axle, 28h, straight-pull, 6-bolt, 78T

Tires

  • Front: Maxxis Assegai MaxxTerra 29×2.5" WT 3C EXO E-25 TLR
  • Rear: Maxxis Dissector MaxxTerra 29×2.4" WT 3C EXO+ E-25 TLR

Handlebar

  • Amflow Enduro Carbon Handlebar
  • 25mm rise, 800mm wide
  • 5-degree upsweep, 9-degree backsweep

Grips

  • Amflow Enduro Grips

Stem

  • Amflow Enduro Stem, One-piece CNC
  • Length: 35mm
  • Clamping diameter: 35mm

Saddle

  • Ergon SM PRO M/L

Seatpost

  • Fox Transfer Factory, Travel adjustable in 5mm
  • M: 125-150mm
  • L/XL: 155-180mm
  • XXL: 185-210mm

Accessories

  • Quick Start Guide
  • Torque Wrench (3~25 N·m, Hex 2/3/4/5/6mm, Torx® 25
